Title: How to Remove the Front Bumper Cover on a 2019 Mercedes E350 (DIY Guide)
Hey everyone,
I recently had to take off the front bumper cover on my 2019 E350 (W213 chassis), and I figured I’d document the process here for anyone looking to do the same—whether you’re replacing the bumper, installing aftermarket parts, or doing some repair work behind it.
With a few tools and a little perseverance, this is totally possible at home. I’d rate the job as moderate in difficulty, mostly because of all the clips and hidden screws. This is a detailed guide based on my personal experience.
🚧 Tools You’ll Need:
- Torx screwdrivers (T25 and T30)
- Flathead screwdriver or trim removal tool
- 10mm socket and ratchet
- Plastic pry tool (highly recommended to avoid scratches)
- Jack and jack stands (optional but helpful)
- Blanket or foam pad (to place the bumper on once removed)
🔧 Step-by-Step Instructions:
1. Prep the Car
- Turn off the ignition and disconnect the negative battery terminal if you’re going to unplug any sensors.
- Put the parking brake on and park on a level surface.
- You might want to lift the car slightly to give yourself more room, especially if you’re working solo.
2. Remove the Underbody Shield
- The front undertray is fastened to the bumper by a number of 8mm or 10mm bolts.
- You’ll also find a few plastic clips—use your trim removal tool or a flathead screwdriver to gently pop them out.
- Once the shield is off, you’ll have access to some of the bolts that hold the bumper in place.
3. Wheel Well Screws
- Turn the wheels to one side to access the inside of the fender.
- Along the edge where the bumper and wheel liner (often T25 Torx) meet, remove the screws.
- Repeat on both sides.
- Gently pull the liner back to expose more screws behind it—there’s often a sneaky one that goes up into the bumper from underneath.
4. Top Grille Screws
- Open the hood and look at the area just above the grille.
- Remove the plastic radiator cover (there are clips and a few bolts).
- Underneath, you’ll find a row of Torx or 10mm bolts that go through the bumper into the radiator support—remove these.
Must Read: How To Remove CLS450 Front Bumper Cover Forum?
5. Side Clips and Separation
- Now comes the delicate part. Where the bumper meets the fender, there’s a set of hidden clips holding it in.
- Gently peel the bumper off the fender using a plastic pry tool. Be careful—it’s easy to break these clips if you pull too hard or in the wrong direction.
- You might need a second person to help support the bumper as you work each side loose.
6. Unplugging Electrical Connectors
- Before fully removing the bumper, check behind it for fog light connectors, parking sensors, or camera wires.
- Carefully disconnect each one. Most connectors have a small tab you press before pulling them apart.
7. Lift Off the Bumper
- With everything loose and unplugged, carefully lift the bumper away from the car.
- Lay it down on a soft blanket or foam pad to avoid scratches.
🛠️ Extra Tips:
- Label your screws and bolts as you remove them—it’ll save you time during reassembly.
- Take photos as you go. Trust me, you’ll be glad you did when you’re putting it all back together.
- If your bumper has any chrome trim or sensors, handle with extra care—they can be fragile and expensive to replace.
✅ Conclusion:
That’s it! Removing the front bumper cover on a 2019 E350 isn’t overly complicated, but it does take some finesse and patience. Whether you’re upgrading the grille, repairing damage, or installing a radar system, having access behind the bumper is essential.
I’d be pleased to assist you if you have any questions or if I missed any steps. And if anyone wants pics, I can upload those too.
Stay safe and wrench on! 🔧
